| Power Supply | 220 VAC (+ 10% to 15%), 50 Hz (±3 Hz) |
| Working Temperature | 5 °C to 40 ° C (41 °F to 104 °F) |
| Working Humidity | 0% to 90% |
| Dimension (W × H × D) | 3200 mm x 1648 mm x 1728 mm (125.98" x 64.88" x 68.03") |
| Operation System | windows |
| Tunnel Size | 1005mm Wx802 mm H |
| Max. load | 200 kg (440.92 lb) |
| Conveyor speed | 0.22 m/s |
| Penetration | top view : 34mm standard, 40+mm by customize side view : 32mm standard, 40+mm by customize |
| Wire resolution | top view : 38AWG side view : 36AWG |
| Spatial resolution | Vertical: 1.3mm；Horizontal: 1.3mm |
| Power Consumption | 1.5 kw |
| X-ray dose per inspection | < 3.5 μGy |
| X-ray leakage | < 0.5 μGy/h |
| X-ray generator | Anode Voltage: standard 160 kV, 100% Oil Cooling, Generator 1, vertical beam direction. Generator 2, horizontal beam direction |
