| Power Supply | 220 VAC (+ 10% to 15%), 50 Hz (±3 Hz) |
| Working Temperature | 5 °C to 40 ° C (41 °F to 104 °F) |
| Working Humidity | 0% to 90% |
| Dimension | 3148.5 mm x 1305 mm x 1648 mm (123.96" x 51.38" x 64.88") |
| Operation System | windows |
| Tunnel Size | 1000mm Wx800 mm H |
| Max. load | 200 kg (440.92 lb) |
| Conveyor speed | 0.22 m/s |
| Penetration | 34mm standard, 40+mm by customize |
| Wire resolution | 38AWG standard |
| Spatial resolution | Vertical: 1.3 mm Horizontal: 1.3 mm |
| Power Consumption | 1 kw |
| X-ray dose per inspection | < 3.5 μGy |
| X-ray leakage | < 0.5 μGy/h |
| X-ray generator | Anode Voltage: standard 160 kV, 100% Oil Cooling, Single generator, vertical beam direction. |
