| Protocol | HTTPS, RTSP, NTP, FTP |
| API | ISAPI,SDK,ISUP |
| Operating Condition | -20 °C to 55 °C (-4 °F to 131 °F). Humidity 95% or less (non-condensing) |
| Power | 5 VDC, 2.0 A, max. 10 W |
| Dimensions | 95 mm × 60 mm × 31.5 mm (3.7" × 2.4" × 1.2") |
| Operating System | Android 9.0 |
| Client | Hik-Connect,HikCentral Pro,HikCentral Master |
| MIC | Supported |
| Speaker | 1 built-in speaker(s), max. power consumption: 1 W, max. sound pressure level: 92 dB (10 cm) |
| Vibration Motor | Not supported |
| Gyroscope | Optional |
| Image Sensor | 1/3 progressive scan CMOS" |
| Max. Recording Resolution | 2688 × 1512 |
| Min. Illumination | Color: 0.15 Lux @ (F2.0, AGC ON), 0 Lux with supplement light |
| Day & Night | Switch IR cut filter automatically |
| Zoom | 4 × digital |
| White Light | Supported |
| Focal Length | 2.4 mm fixed lens |
| FOV | Horizontal FOV: 134°, Vertical FOV: 75°, Diagonal FOV: 154° |
| Aperture | F2.0 |
| Video Compression | H.264,H.265 |
| Video Format | MP4,PS |
| Main Stream | 60 Hz: 30 fps (2688×1512,1920 × 1080, 1280 × 720, 720 × 576) |
| Pre-record & Post-record | Pre-record: 60/10/5/3 s, Post-record: 60/10/5/3 s |
| Sub-Stream | 30 fps (1920 × 1080, 1280 × 720, 720 × 576) |
| Image Format | JPEG |
| Image Resolution | 5 MP, 16 MP, 30 MP, 40 MP |
| Indicator | 2 indicator(s) for charging/working/recording/exception |
| Button | Power,Video recording,SOS,PTT,Picture capture,Audio recording |
| SIM Card | SIM card slot(fit for nano-SIM card) |
| Charging Interface | Mini USB, Pogo Pin |
| USB | 1 USB 2.0 port(s) |
| Laser Positioning | Supported |
| Basic Event | SOS alarm |
| RF | EN 300 328 V2.1.1 (BT or 2.4G),EN 62311:2008 (BT or 2.4G),EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013,EN 50130-4:2011+A1:2014) |
| EMC | CE-EMC: EN 55032: 2015,EN 61000-3-2: 2019,EN 61000-3-3: 2013,EN 50130-4: 2011 +A1: 2014 |
| Safety | CB: IEC 62368-1: 2014+A11,IEC 62368-1: 2018,CE-LVD: EN 62368-1: 2014/A11: 2017,EN IEC 62368-1:2020+A11:2020,CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006 |
| Protection | IP67: IEC 60529-2013 |
| Audio Compression for Video Recording | AAC,G722 |
| Audio Compression for Audio Recording | PCM |
| Audio Compression for Group Intercom | G711.A,G711.U,G722 |
| Audio Bit Rate | G722(16 kbps) ,AAC(dynamic),PCM(256 kbps),G711.A(64 kbps) ,G711.U(64 kbps) |
| IR Range | Up to 10 m |
| IR Wavelength | 850 nm |
| Battery Type | Lithium-ion battery, dismountable |
| Capacity | 3300 mAh |
| Charging Time | ≤ 4 h |
| Battery Duration | Up to 12 h in 720p resolution¹ |
| RAM | 2 GB |
| ROM | 64 GB by default, 128/256 GB optional |
| Display Resolution | 320 × 240 |
| Screen Size | 2.4" |
| Touchscreen | Supported |
| Screen Brightness | Typical value: 520 cd/m² |
| Bluetooth | BT4.2 |
| Wi-Fi Protocol | 802.11 b/g/n |
| Wi-Fi Frequency Band | 2.412 to 2.472 GHz |
| Cellular Network | Only available for models with /GLE : GSM: 850/900/1800/1900 WCDMA: B1/B8 FDD -LTE: B1/B2/B3/B4/B5/B7/B8/B20/B28 TDD -LTE: B38/B39/B40/B41 |
| Positioning Mode | GPS |
| NFC | Optional |
| Warranty | 2 years for the device without battery, 1 year for the battery |
| CPU | 8 cores, 64 bit, Main frequency: 1.8 GHz |
| Encryption | AES128, AES256 |
| Watermark | Supported |
| Image Stabilization Algorithm | GIS: optional |
| Group Intercom | Supported for firmware version V2.6.0 or above |
| Drop Test | MIL-STD-810G, 2 m drop test |
| Face Picture Capture | Supported |
| Face Picture Recognition | Optional |
| License Plate Recognition | Optional |
