| Camera Material | plastic |
| Camera Dimension | 76.1 mm × 74.2 mm × 37.9 mm (2.9" × 2.6" × 2.3") |
| Startup and Operating Conditions | -40 °C to 75 °C (-40 °F to 167 °F), 90% |
| Shutter Speed | 1/25 s to 1/30,000 s |
| P/N | NA |
| Wide Dynamic Range | NA |
| Day & Night | Electronic |
| Lens Mount | M12 |
| Frame Rate | 1080p@25 fps |
| SNR | 42 dB |
| Video Output | TVI |
| Built-in Microphone | yes |
| Built-in Speaker | NO |
| Audio | yes |
| Interface Style | 1 Vpp Composite Output (aviation plug) 1: video, 2: Audio, 3: power, 4: ground |
| Power Supply | 9 to 16 V DC |
| Power Consumption | Max. 2.2 W |
