| Camera Dimension | 74 .8mm × 48.2 mm × 43 mm (2.9" × 1.9" × 1.7") |
| Startup and Operating Conditions | -40 °C to 75 °C (-40 °F to 167 °F), 90% |
| Shutter Speed | 1/25 s to 1/30,000 s |
| Wide Dynamic Range | 96 dB |
| Day & Night | Color |
| Lens Mount | M12 |
| Frame Rate | 720P@30 fps |
| SNR | 42 dB |
| Video Output | 1, Vp-p Composite Output (aviation plug) |
| Audio | 1, aviation plug (linear resistance: 1 kΩ) |
| Interface Style | 1 Vpp Composite Output (aviation plug) 1：power, 2:ground ,3:NA ,4：video |
| Power Supply | 9 to 16 V DC |
| Power Consumption | Max. 1 W |
